XL550 2 Channel Power Amplifier Balanced Input Two Channel Power Amp 2×800W

Product Categories

Professional Power Amplifier [82]
Digital Power Amplifier [11]
Class TD Power Amplifier [10]
2 Channel Power Amplifier [72]
4 Channel Power Amplifier [30]
Public Address System Amplifier [19]
Karaoke Power Amplifier [43]
Stage Power Amplifier [37]
Professional Audio Speaker [16]
Karaoke Loud Speaker [8]
Digital Audio Cable [12]

Foshan Subole Electronic Technology Co., Ltd.

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

XL550 2 Channel Power Amplifier Balanced Input Two Channel Power Amp 2×800W

Name: XL550 2 Channel Power Amplifier Balanced Input Two Channel Power Amp 2800W
Brand: P-AMF
Price: 1 USD

Brand Name : P-AMF

Model Number : XL550

Certification : CE,ISO

Place of Origin : china

MOQ : 30PCS

Price : Negotiable

Payment Terms : T/T, Western Union, MoneyGram

Supply Ability : 300PCS/month

Delivery Time : 30-60days After Deposit

Packaging Details : 482×339.5×88（mm）

Name : 2 Channel Power Amplifier

4 OHMS : 2×800W

Noise A-weighting : ＞100dB

Brand customization : OEM/ODM

Channel Separation : ＞70dB

Packing Details : Cartons and Plastic Bags

MOQ : 100

Contact Now

2 channel XL550 Professional Power Amplifier Balanced input

Description

High Efficiency: Professional power amplifiers are designed to operate efficiently, converting a larger portion of the electrical power from the power supply into useful audio power. This efficiency helps reduce power consumption and heat generation, making them more suitable for prolonged use in demanding applications.

Quick Detail

Model		XL-550
TA 1KHz THD≤1% Stereo Power	8 OHMS	2×550W
	4 OHMS	2×800W
TA 1KHz THD≤1% Bridge Mono Power	8 OHMS	1500W
Frequency Response		10Hz-50KHz-1.5dB
Noise A-weighting		＞100dB
Damping Coefficient		＞200
Maximum Input Level		21dBV/9V
Slew Rate		≥35V/μS
Channel Separation		＞70dB
Input Sensitivity		0.77V/1V/1.4V
Input Impedance(Equilibrium/Disequilibrium)		20K OHMS/10K OHMS
Output Type		Class A
Power Dissipation (half-power,8 OHMS)		＜430W
Power Source		220V-240V/50Hz
Cooling		Two variable speed fans
Protection		DC / short circuit / over voltage over current protection / soft start / power amplifier tube overheat protection / distortion limiting
Display		Power light (green), Protection light (red), Overload light (yellow), Signal light (green)
Input		Balanced input
Output		Professioanl binding post outputs
Panel Control		Left and right channel volume control, power switch control
Backplane Control		Parallel / bridge mono switch, 0.77v/1v/1.4v sensitivity switch
Dimension (mm)		482×339.5×88(mm)

Advantage Of Factory

Our company was established in 1998, specializing in the development, production, and sales of audio electronic products for over 20 years. Complete equipment, advanced production technology, multiple high-efficiency assembly lines, semi-automatic production, ensuring quality and quantity. With strong technology and advanced management experience, perfect after-sales service (for example: after-sales troubleshooting, maintenance consulting, spare parts replacement, etc.) based on the forefront of the audio industry, dedicated to new and old customers for a better tomorrow.
